TempGuard Hinged Y Piece fittings
One-piece asymmetrical 3 junction fittings allow a variety of conduit variations. These fittings are designed to snap together over all types of slit and unslit Harnessflex conduit, maintaining maximum conduit bore. Can be used as an in-line reducer as well as an enlarger. Full TempGuard system protection is achieved using these fittings with HTC conduit.
| Temperature Range | |
| Minimum | -40ºC |
| Permanent Max | 160ºC |
| Long term max (30,000 hrs) | 185ºC |
| Short term max (3,000 hrs) | 200ºC |
Features
- One-piece external design for unrestricted bore and quick assembly with no tools.
- High pull-off strength – conduit corrugations sit tightly into joiner junctions.
- Conduit size labels – each junction indicates nominal conduit size to aid installation
- High Temperature Polyamide (Nylon) – Low Smoke & Halogen Free
- IP40 rated
- High UV resistance
Conformity
- CE Mark to the low voltage directive
- RoHS Compliant to 2011/65/EU
- Conforms with end of life vehicle directive (ELV) EU200/53/EC
- UL94 V2 / UL94 RTI 150 (Elec)
